Applications:
Premier's Glow wire testing is an electrical safety test designed to evaluate the flame resistant properties of plastic materials used in electrical devices. Its purpose is to protect against the risk of fire from overheated or electrically energised parts which may cause the plastic material to ignite.
GLOW WIRE TEST
MODEL : PE 8000
Premier's Glow Wire Test Appratus for checking of Resistance of insulating material to abnormal heat and fire
TECHNICAL SPECIFICATIONS
TEMPERATURE CONTROLLER SECTION:
- Display: 4 digit, 12.5mm ht, red LED for Process Value
- 4 digit, 12.5mm ht, red LED for Set Value
- Input: Cr/AL 'K' type Thermocouple
- Range: 0 to 1200°C
- Resolution: 1°C
- Accuracy: +/- 0.5% +/- 1 count
- Control Action: PID or ON/OFF (selectable)
- Setting: By means of Membrane key Switches
- Output: One Changeover relay contact
PRESET TIMER SECTION:
- Display: 4 digit, 12.5mm ht, red LED for Process Value
- 4 digit, 12.5mm ht, red LED for Set Value
- Range: 0 - 999.9 Sec
- Resolution: 0.1 Sec
- Accuracy: 0.05% +/- 1 count
- Input: from Limit Switch /relay contact
- Set Point: One No, Adjustable by membrane key switches
- Output: Internal to start Time Interval Meter
TIME INTERVAL METER SECTION:
- Display: 4 digit, 12.5mm ht, red LED
- Range: 0 - 999.9 Sec
- Resolution: 0.1 Sec
- Accuracy: 0.05% +/- 1 count
- Input: from Preset Timer - Internal
- Stop: Push button provided - Manual
TEMPERATURE RISE TEST:
- Test Voltage: 0 to 6 V AC measured on 4 digit 0.5" ht. red LED Display, 0 - 20.00 Volt range
- Resolution: 0.01 Volt
- Accuracy: 0.6% +/- 1 count
- Test Current: 0 - 30.0 Amp Continuously adjustable by means of variac Display, 0 - 30.0 A
- Resolution: 0.1 A
- Accuracy: 0.6% +/- 1 count
FACILITIES:
- Push Button Controls for Glow Wire Test ON
- Temp Rise Test ON
- Test OFF/OVER
- External Temperature measurement selector switch with i/p terminals
